General features
Vehicle gear mineral oil with very good lubricating, antioxidative, anticorrosive and antifoaming properties.
Application
Mineral oil intended to lubricate gears of vehicles operating in very difficult conditions, especially for gearboxes and final drives, where API GL-5 oil is recommended, it is featured by perfect properties guaranteeing maximal protection against mechanical wear out.
Standards, approvals, specifications
Approval for use in the side gear shaft and the housing track frames in the heavy equipment of Huta Stalowa Wola (HSW)
Physical and chemical properties
Parameters |
Unit |
Typical values |
Quality class according to SAE J 306-OCT 91 |
- |
80W-90 |
Kinematic viscosity at 100°C |
mm2/s |
14.5 |
Viscosity index |
- |
99 |
Flow temperature |
0C |
-30 |
Solidification point |
0C |
- |
Ignition temperature |
0C |
220 |
Resistance to foaming: · foam volume after 5 min. of air blowing at 25°C/95°C/25°C following the test at 95°C · foam volume after 10 min. standing still at 25°C/95°C/25°C following the test at 95°C |
ml |
10/20/10 0/0/0 |
Corrosiveness to copper 3 h/120°C, corrosion rate |
reference sample |
2b |
Lubricating properties on a four ball pressure tester: · weld load, · loaded wear ratio |
kG |
400 56 |
ATTENTION: Physicochemical parameters listed in the table are typical values. Real values are stated in quality control certificates attached to each product lot. |
